DC Surge Protective Device -for Maximum Equipment Safety

DC-powered systems receive protection from the DC Surge Protective Device against lightning and electrical disturbances in the form of voltage surges. The device safeguards sensitive equipment that includes solar power systems together with battery storage by defending them against destructive transient voltages. This protection device operates best when installed in both renewable energy systems and other Direct Current systems.

Amazon Surge Protector -BT P DCM 48 RM-1

BT P DCM 48 RM-1 811055 1. DC UN 12V/24V/36V/48V/60V/110V/220V Optional.
2. Combined DC SPD, slim 18mm form factor.
3. Pluggable module, easy for installation and maintenance.
4. High discharge capacity, quick response.
5. Double thermal disconnector device, providing more reliable protection.
6. Multifunctional terminal for connecting conductors and busbars.
7. Windows will change to red when fault and also provide remote alarm control at the same time.

48V DC Surge Protector

Surge Protector for 220V -BT P DCM 220 RM-1

BT P DCM 220 RM-1 811056 1. DC UN 5V/12V/24V/48V/110V/220V Optional.
2. Combined DC SPD, slim 18mm form factor.
3. Pluggable module, easy for installation and maintenance.
4. High discharge capacity, quick response.
5. Double thermal disconnector device, providing more reliable protection.
6. Multifunctional terminal for connecting conductors and busbars.
7. Windows will change to red when fault and also provide remote alarm control at the same time.

220V DC Surge Protector

24V Surge Suppressor -BT P DCM 24 RM-1

BT P DCM 24 RM-1 811054 1. DC UN 5V/12V/24V/48V/110V/220V Optional.
2. Combined DC SPD, slim 18mm form factor.
3. Pluggable module, easy for installation and maintenance.
4. High discharge capacity, quick response.
5. Double thermal disconnector device, providing more reliable protection.
6. Multifunctional terminal for connecting conductors and busbars.
7. Windows will change to red when fault and also provide remote alarm control at the same time.

24V DC Surge Protector

60V DC Surge Protector -BT P BDCM25 48 RM/2P

BT P BDCM25 48 RM/2P 802044 1. Pluggable module, 10/350us and 8/20us sparkgap (GDT).
2. Lightning discharge current up to 25kA for use in dccircuits applications.
3. High discharge capacity, quick response.
4. Double thermal disconnector device, providing more reliable protection.
5. Green window will change when fault and also provide remote alarm control at the same time.

T1+T2 DC Power Surge Protector

DC SPD 1000V -BT Y PVM 1000 MG RM

BT Y PVM 1000 MG RM 800567 1. Combined class II DC surge protector for Photovoltaic(PV) System.
2. Pluggable module, easy for installation and maintenance.
3. Approved falult-resistant Y-circuit, consist of two varistors and GDT module of thermal disconnection devices.
4. High discharge capacity, quick response.
5. Double thermal disconnection device, providing more reliable protection.
6. Integrated DC-fuse allows safe replacement of protection modules without arc formation.
7. Green window will change when fault and also provide remote alarm control at the same time.
8. Advanced Western European technology guarantees ultra-reliable PV surge protection.

1000V DC Surge Protector

48V DC Surge Protector -BT P BDCM25 48 RM

BT P BDCM25 48 RM 802048 1. Pluggable module, 10/350us and 8/20us sparkgap (GDT).
2. Lightning discharge current up to 25kA for use in dccircuits applications.
3. High discharge capacity, quick response.
4. Double thermal disconnector device, providing more reliable protection.
5. Green window will change when fault and also provide remote alarm control at the same time.

T1+T2 DC Power Surge Protector

DC Surge Protective Device

The Power Supply System SPD protects through a combination of AC SPD Class I and II along with SPD boxes and photovoltaic DC SPD followed by gas-type AC SPD and extension SPD and wind turbine SPD and surge protectors for IT and network and security systems. This equipment provides accessory protection which includes ground devices and lightning counter equipment.
