Reliable and Affordable T2 Surge Protective Device

The AC T1+T2 Surge Protective Device is the best protection for your power systems. Combining T1 and T2 surge protection, it is intended for energy surges in units of lightning discharge, power failure, and other transverse voltage fluctuations. Because of the rapid rechargeability and high discharge turn, this battery will always safeguard your electrical appliances most effectively. This gadget promises protection and reliability in industrial and commercial use and settings, as well as in homes.

Din Rail Surge Protector -BT P BCM25 255 RM

BT P BCM25 255 RM 801 400 1. Pluggable module, N-PE(GDT) module.
2. High discharge capacity, quick response.
3. Double thermal disconnector devices, providing more reliable protection.
4. Green windows will change to red when fault and also provide remote alarm control at the same time.
5. BT P BCM25 255 RM has passed TUV CB CE RoHS certificate.
6. Mode of protection: N-PE

AC T1+T2 Surge Protective Device

Din Rail Surge Suppressor -BT P BCM12.5 275 RM/2+N

BT P BCM12.5 275 RM/2+N 801 437 1. 10/350us 12.5kA for two phase AC system.
2. Consist of MOV+GDT and thermal disconnection device.
3. High discharge capacity, quick response, pluggable.
4. Mode of protection: L-N/N-PE.
5. Multifunctional connection for conductors and busbars.
6. Green window will change to red when fault and also provide remote alarm control at the same time.

AC T1+T2 Surge Protective Device

Industrial Power Surge Protector -BT P BCM12.5 275 RM

BT P BCM12.5 275 RM 801406 1. 10/350us 12.5kA, 8/20us 30-65kA.
2. Consist of varistor and thermal disconnection device.
3. High discharge capacity, quick response, pluggable.
4. Double thermal disconnection devices, providing more reliable protection.
5. Multifunctional connection for conductors and busbars.
6. Mode of protection: L-N; L-PE; N-PE; L-PEN.
7. Green window will change to red when fault and also provide remote alarm control at the same time.

AC T1+T2 Surge Protective Device

Home Lightning Protection System -BT P BCM 25 RM/3+N-S

BT P BCM 25 RM/3+N-S 800899 1. Three-phase protection for TT/TN-S system ( “3+1” circuit).
2. Adopt hermetical High Energy Gas Discharge Tube(GDT) technology, high follow current extinguishing capability.
3. Extremely low voltage protection level.
4. Double thermal disconnection device , provide more reliable protection.
5. Multifunctional connection for conductors and busbars.
6. Green window will change to red when fault occurs, also provide remote alarm terminal at the same time.
7. Suitable for use in three phase 380V/400V/415V AC 50/60 Hz systems.
8. Mode of protection:L-N;N-PE.
9. Crafted from selected flame-retardant enclosure and Utilizing advanced European technology to ensure complete and reliable safeguarding of electrical equipment.

AC T1+T2 Surge Protective Device

Whole Home Lightning Protection System -BT P BCM 25 RM/2+N-S

BT P BCM 25 RM/2+N-S 800897 1. Two-phase protection for TT/TN system ( “2+1” circuit).
2. Adopt hermetical High Energy Gas Discharge Tube(GDT) technology, high follow current extinguishing capability.
3. Extremely low voltage protection level.
4. Double thermal disconnection device , provide more reliable protection.
5. Multifunctional connection for conductors and busbars.
6. Green window will change to red when fault occurs, also provide remote alarm terminal at the same time.
7. Suitable for TT/TN installations.
8. Mode of protection: L-N;N-PE.
9. Crafted from selected flame-retardant enclosure and Utilizing advanced European technology to ensure complete and reliable safeguarding of electrical equipment.

AC T1+T2 Surge Protective Device

Surge Suppressor Industrial -BT P BCM 25 RM/1+N-S

BT P BCM 25 RM/1+N-S 800898 1. Single-phase protection for TT/TN system ( “1+1” circuit).
2. Adopt hermetical High Energy Gas Discharge Tube(GDT) technology, high follow current extinguishing capability.
3. Extremely low voltage protection level.
4. Double thermal disconnection device , provide more reliable protection.
5. Multifunctional connection for conductors and busbars.
6. Green window will change to red when fault occurs, also provide remote alarm terminal at the same time.
7. Suitable for use in single phase 220V-240V AC systems.
8. Suitable for TT/TN installations.
9. Mode of protection: L-N;N-PE.
10. Crafted from selected flame-retardant enclosure and Utilizing advanced European technology to ensure complete and reliable safeguarding of electrical equipment.

AC T1+T2 Surge Protective Device

Product Range

Explore our Power Supply System SPD solutions for all your surge protection needs.

AC SPD Class I and II: Offer formats of security in the form of two layers.

SPD Boxes: Solutions that are local and less centralized to accommodate surge volumes.

Photovoltaic DC SPD: Specific purpose controller for a solar power system.

Gas-Type AC SPD: Consequently, it becomes possible to guarantee the very highest level of protection on board using the gas discharge technology.

Extension SPD: UV shield that is easy to wear and adapt, thus may complement and apply to various lifestyles.

Wind Turbine SPD: In addition, integrated particularly for renewable power plants —
IT, Network, and Security SPD: Of importance is in safeguarding principal systems.

The Bottom Line

The AC T1+T2 Surge Protective Device is the perfect product to shield the power systems of any person. Whether for residential, commercial, or industrial use it enables continuity and system in operations and safeguards valuable properties.
