Home Depot Surge Protector -BT P BCM 320 RM/3P

Home Depot Surge Protector BT P BCM 320 RM/3P（801303）designed for installation in LPZ 0A-2 or higher zones, this surge protection device safeguards low-voltage equipment from power surges and remote terminal is optional. Application: Pluggable SPD Class I + Class II for three phase TN-C("3+0" circuit) various power supply systems. Compliance Standards:IEC 61643-11:2011;EN 61643-11:2012;GB/T 18802.11-2020.

Type

BT P BCM 320 RM/3P
Art.-No.

801303
Features

1. Pluggable module, easy for installation and maintenance.
2. Double thermal disconnector devices, providing more reliable protection.
3. Max. lightning discharge current up to 8kA(10/350μs)and High discharge capacity, quick response.
4. Green window will change when fault and also provide remote alarm control at the same time.
5. Mode of protection:L-PEN.
6. Suitable for TN-C installations.
7. Crafted from selected flame-retardant enclosure and Utilizing advanced European technology to ensure complete and reliable safeguarding of electrical equipment.

Inquiry

Download Datasheet

LMode of protection: L-PEN System: TN-C

Modules: 3P Uc 150V/275V/320V/385V AC

Surge Ratings: Iimp=8kA(10/350μs), In=25kA(8/20μs)

High Surge Currents: Imax=50kA(8/20μs)

Housing: Pluggable Design/Red flame retardant material

Home Depot Surge Protector supports daily home power protection against voltage spikes caused by storms, grid switching, and appliance startup. Designed for outlets and power strips, it limits surge energy before it reaches sensitive electronics. LED indicators show protection status for easy checks without tools. Compact housing fits behind furniture or entertainment centers without blocking nearby sockets. Use it with televisions, routers, gaming consoles, kitchen appliances, and charging stations. Choose suitable joule ratings and outlet counts based on connected loads, and place the unit close to the protected devices for better surge control. Built for regular household use, it helps reduce sudden damage risks during unpredictable power conditions.

Features

1. Surge Energy Absorption: Limits sudden voltage spikes before they reach connected household electronics.
2. LED Protection Indicator: Displays working status for quick visual confirmation.
3. Compact Plug-In Design: Fits wall outlets and power strips without blocking nearby sockets.
4. Multiple Outlet Options: Supports connection of several home devices from one location.
5. Fire-Resistant Housing: Uses heat-tolerant materials for safer indoor operation.
6. Standard Grounding Support: Works with grounded outlets commonly found in residential wiring.

Advantages

1. Reduced Appliance Damage Risk: Helps lower the chance of sudden failure caused by voltage spikes.
2. Clear Status Awareness: Visual indicators simplify daily checks without unplugging devices.
3. Space-Friendly Use: Small footprint suits living rooms, bedrooms, and offices.
4. Easy Setup: Plug-in format requires no wiring or special tools.
5. Added Peace Of Mind: Supports stable power conditions during storms or grid fluctuations.
6. Suitable For Mixed Loads: Handles entertainment, networking, and charging equipment together.

Applications

1. Television And Home Theater Systems: Protects TVs, soundbars, and media players from surge damage.
2. Wi-Fi Routers And Modems: Supports stable power for home networking equipment.
3. Gaming Consoles And PCs: Reduces spike impact on sensitive gaming and computing devices.
4. Kitchen Countertop Appliances: Guards coffee makers, microwaves, and small appliances.
5. Home Office Power Strips: Covers monitors, printers, and charging docks in workspaces.
6. Bedroom Charging Stations: Protects phones, tablets, and wearable chargers overnight.

Technical Data

Product Showcase

Start Your Project

We will respond to you within 24 hours after receiving your request email.

3 Years Warranty
Free Customized Design
Welcome OEM and ODM Service
CE RoHS CB KEMA TUV Certificates
Surge Protecetive Device（SPD）Factory
30+ Years Surge Protector SPD Experiences

Type	BT P BCM 150 RM/3P	BT P BCM 275 RM/3P	BT P BCM 320 RM/3P	BT P BCM 385 RM/3P
Art.-No.	801123	801103	801303	801153
According to IEC 61643-11/EN 61643-11	Class I + Class II / Type 1 + Type 2
Nominal a.c. voltage [U_N](50/60 Hz)	120V/240V	230V/400V	230V/400V	230V/400V
Rated voltage (max. continuous voltage) [Uc] (50/60Hz)	150V	275V	320V	385V
Lightning impulse current (10/350μs) [I_imp]	8kA	8kA	8kA	8kA
Nominal discharge current (8/20μs) [In]	25kA	25kA	25kA	25kA
Max. discharge current (8/20μs) [Imax]	50kA	50kA	50kA	50kA
Voltage protection level at In [Up]	≤ 1.25kV	≤ 1.5kV	≤ 1.65kV	≤ 1.8kV
Response time [tA]	≤ 25ns
Max. back up fuse [F]	125A gL/gG
Operating temperature range [Tu]	-40°C…+80°C
Operating state / Failure indication	Green: ok / Red: faulty
Cross-sectional area	1.5mm² (16AWG)~25mm² (4AWG) solid / 35mm²(2AWG) flexible
Mounting on	35mm DIN rail, EN 60715
Number of remote terminals	1(or Optional)
Enclosure material	Red module & light gray (base) thermoplastic, UL94-V0
Dimension	3 mods (54mm wide)
Degree of Protection	IP 20
Place of installation	Indoor
Compliance	IEC 61643-11:2011 ; EN 61643-11:2012; GB/T 18802.11-2020
Certification	CE; RoHS
Type of remote signaling contact	Switching contact
Switching capacity a.c.	250V/0.5A
Switching capacity d.c.	250V/0.1A, 125V/0.2A, 75V/0.5A
Cross-sectional area for remote signaling contact	Max. 1.5mm² (16AWG) solid/flexible
